Главная Каталог продукции Toolunited 10 302-02 - Step drill TG203344.103533

TG203344.103533

Артикул: TG203344.103533

В наличии

В корзину

Описание

Характеристики

CCONMS Connection count machine side

CNSC Coolant entry style code

4 - With Coolant entry, axial on hole circle

COATN Coating

TIALN-T14

COMPC Company code

E - Emuge

CXSC Coolant exit style code

4 - With Coolant exit, axial on hole circle

DC Cutting diameter minimum

10.35 mm

DCONMSLD Shank diameter lower limit

-0.011 mm

DCONMSUD Shank diameter upper limit

0 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

2/1/2024

DIN

ZYL01400115

DRSYC Drill tool style code

2 - subland step drill

FamilyProducts

Chamfer drill

FHA Flute helix angle

26.5 Degree

FHH Flute helix hand

R - Hand of helix right

FHP Flute helix pitch

65.2 mm

GRDMFG Grade manufacturers designation

K45F

GRDPRIO Standard designation of the grade main application

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

302-02 - Step drill

LCF Length chip flute

61 mm

LF Functional length

105.115 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0140

LOC-03 DCONMS Diameter

14 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01400115

LPR Protruding length

62 mm

LS Shank length

45 mm

LU Usable length

36.746 mm

Name Identifying order number

TG203344.103533

NOF Flute count

NOS Step count

OAL Overall length

107 mm

PL Point length

1.885 mm

SDL Step diameter length

33 mm

SIG Point angle 1st step

140 Degree

Working process

BVB - Drilling

WT Weight of item

0.174 kg
