Главная Каталог продукции Toolunited 10 302-01 - Twist Drill TE213324.0130

TE213324.0130

Артикул: TE213324.0130

В наличии

В корзину

Описание

Характеристики

CCONMS Connection count machine side

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COATN Coating / Покрытие

TIALN-T99

COMPC Company code

E - Emuge

CXSC Coolant exit style code

4 - With Coolant exit, axial on hole circle

DC Cutting diameter minimum

1.3 mm

DCONMSLD Shank diameter lower limit

-0.008 mm

DCONMSUD Shank diameter upper limit

0 mm

DCP Data chip provision

0 - Without data chip

DIN

ZYL00400115

FamilyProducts

EF-Drill-Micro-ST-6xD-AI2-TA99

FHA Flute helix angle

25 Degree

FHH Flute helix hand

R - Hand of helix right

FHP Flute helix pitch

8.76 mm

GRDMFG Grade manufacturers designation

K45F

GRDPRIO Standard designation of the grade main application

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

302-01 - Twist Drill

LCF Length chip flute

11.7 mm

LF Functional length

56.763 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0040

LOC-03 DCONMS Diameter

4 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00400115

LPR Protruding length

17 mm

LS Shank length

40 mm

LU Usable length

7.8 mm

Name Identifying order number

TE213324.0130

NOF Flute count

OAL Overall length

57 mm

PL Point length

0.237 mm

SIG Point angle 1st step

140 Degree

STDLET Standard letter to the standard number

STDNO Standard

DIN 6537

TCDCONMS ISO-tolerance class shank diameter

Working process

BVB - Drilling
