A4411-35.5

A4411-35.5 A4411-35.5 A4411-35.5 A4411-35.5

A4411-35.5

Walter
Артикул: 5066087
В наличии
В корзину
Описание
Характеристики
BMC Body material code
S - Solid steel
CCONMS Connection count machine side
2
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
W - Walter
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter minimum
35.5 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2023
DIN
MKG00402085
FamilyProducts
HSS twist drills with Morse taper, long A4411
FHA Flute helix angle
30 Degree
FHH Flute helix hand
R - Hand of helix right
GRDMFG Grade manufacturers designation
DUMMY
HAND Cutting direction
R - Right
ID Technical product number
5066087
Interface codes
J6 / J61
ISO
MKG20C0040$$$$
ISYC Subclass
302-01 - Twist Drill
LCF Length chip flute
257 mm
LF Functional length
277.83472 mm
LOC-03 CCFMS Form
20
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
MKG Morse taper
LOC-03 CCUMS Unit base
8 non-dimensional size
LOC-03 CZCMS Size code
0040
LOC-03 DCONMS Diameter
4 mm
LOC-03 ISO
MKG20C0040$$$$
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
MKG00402085
LPR Protruding length
288.49997 mm
LU Usable length
221 mm
Name Identifying order number
A4411-35.5
NOF Flute count
2
OAL Overall length
406 mm
PL Point length
10.665276 mm
RPMX Rotational speed maximum
5000 1/min
SIG Point angle 1st step
118 Degree
STDLET Standard letter to the standard number
BE
STDNO Standard
DIN 341
Working process
BVB - Drilling
WT Weight of item
1.701 kg
