A3285TFL-16

Артикул: 5063374

В наличии

В корзину

Описание

Характеристики

BMC Body material code

H - Solid carbide

CCONMS Connection count machine side

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

W - Walter

CXSC Coolant exit style code

3 - With Coolant exit, axial and radial

DC Cutting diameter minimum

16 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

12/1/2023

DIN

ZYL01600115

FamilyProducts

Solid carbide drills with coolant-through A3285TFL

FHA Flute helix angle

30 Degree

FHH Flute helix hand

R - Hand of helix right

GRDMFG Grade manufacturers designation

TFL

HAND Cutting direction

R - Right

ID Technical product number

5063374

Interface codes

J6 / J61

ISO

ZYL01G1600h$06

ISYC Subclass

302-01 - Twist Drill

LCF Length chip flute

65 mm

LF Functional length

112.09 mm

LOC-03 CCFMS Form

LOC-03 CCSMS Style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Type

ZYL cylindrical shank

LOC-03 CCUMS Unit base

1 Metric with coolant

LOC-03 CZCMS Size code

0160

LOC-03 DCONMS Diameter

16 mm

LOC-03 TCDCONCDMS Tolerance class coded

h$06

LOC-03 ISO

ZYL01G1600h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01600115

LPR Protruding length

67.00176 mm

LS Shank length

48 mm

LU Usable length

45 mm

Name Identifying order number

A3285TFL-16

NOF Flute count

OAL Overall length

115 mm

PL Point length

2.9117618 mm

RPMX Rotational speed maximum

100000 1/min

SIG Point angle 1st step

140 Degree

STDLET Standard letter to the standard number

STDNO Standard

DIN 6537 K

TCDCONMS ISO-tolerance class shank diameter

Working process

BVB - Drilling

WT Weight of item

0.254 kg
