Главная Каталог продукции Toolunited 10 301-01 - Thread cutting tap with offset shank MTH-M12X1.00ISO6HX-BC-P011

MTH-M12X1.00ISO6HX-BC-P011

MTH-M12X1.00ISO6HX-BC-P011 MTH-M12X1.00ISO6HX-BC-P011 MTH-M12X1.00ISO6HX-BC-P011 MTH-M12X1.00ISO6HX-BC-P011

MTH-M12X1.00ISO6HX-BC-P011

SECO Tools
Артикул: 03000048
В наличии
В корзину
Описание
Характеристики
BMC Body material code
S - Solid steel
CNSC Coolant entry style code
0 - Without coolant entry
COATN Coating
AlTiN
COMPC Company code
SO - SECO Tools
CXSC Coolant exit style code
0 - Without coolant exit
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2023
DIN
ZYL00902105
FamilyProducts
MTH-M12X1.00ISO6HX-BC-P011
FHA Flute helix angle
48 Degree
GRDPRIO Standard designation of the grade main application
HSS-E-PM
HAND Cutting direction
R - Right
ID Technical product number
03000048
Interface codes
J6 /
ISYC Subclass
301-01 - Thread cutting tap with offset shank
LOC-03 CCFMS Connection code form
21
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0090
LOC-03 DCONMS Diameter
9 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL00902105
Name Identifying order number
MTH-M12X1.00ISO6HX-BC-P011
NOF Flute count
3
OAL Overall length
97.25 mm
PLCD Gate diameter
11.1 mm
PLG Plug style
C - Kappa r 15°
STDNO Standard
DIN374
TCTR Thread tolerance class
6HX
TD Thread diameter
12 mm
THFT Thread form type
MF
THL Thread cutting part length
15 mm
THOD Thread designation
MF12x1-6HX
TP Thread pitch
1 mm
Working process
BG - Tapping
WT Weight of item
0.041 kg
