H0483001.5049
H0483001.5049
Артикул:
H0483001.5049
В наличии
Характеристики
COATN Coating
--
COMPC Company code
E - Emuge
CXSC Coolant exit style code
0 - Without coolant exit
DIN
ZYL01202105
DRVS Drive size
9 mm
FamilyProducts
WM-Satz-GB-2S(1,F)
FHH Flute helix hand
N - Hand of helix neutral
GRDMFG Grade manufacturers designation
HSSE
GRDPRIO Standard designation of the grade main application
HSS-E
HAND Cutting direction
R - Right
Interface codes
J6 /
ISYC Subclass
301-01 - Thread cutting tap with offset shank
LOC-03 CCFMS Connection code form
21
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0120
LOC-03 DCONMS Diameter
12 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
h$09
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL01202105
Name Identifying order number
H0483001.5049
OAL Overall length
70 mm
PLG Plug style
C - Kappa r 15°
STDNO Standard
DIN 2184-2
TCDCONMS ISO-tolerance class shank diameter
h9
TCTR Thread tolerance class
2BX
TD Thread diameter
15.875 mm
TDFR Thread diameter nominal fraction
5/8 in
TDIN Thread diameter nominal inch
0.625 in
THFT Thread form type
UNF
THOD Thread designation
UNF5/8-18-2BX
TP Thread pitch
1.411 mm
TPI Threads per inch
18 1/in
Working process
No working processes available
WT Weight of item
0.114 kg
