CJ45370N.0422
CJ45370N.0422
Артикул:
CJ45370N.0422
В наличии
Характеристики
COATN Coating
TIN
COMPC Company code
E - Emuge
CXSC Coolant exit style code
0 - Without coolant exit
DIN
ZYL01502105
DRVS Drive size
12 mm
FamilyProducts
JIS-Rek.2D-Z-TIN
FHH Flute helix hand
R - Hand of helix right
GRDMFG Grade manufacturers designation
HSSE
GRDPRIO Standard designation of the grade main application
HSS-E
HAND Cutting direction
R - Right
Interface codes
J6 /
ISYC Subclass
301-01 - Thread cutting tap with offset shank
LOC-03 CCFMS Connection code form
21
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0150
LOC-03 DCONMS Diameter
15 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
h$09
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL01502105
Name Identifying order number
CJ45370N.0422
OAL Overall length
125 mm
PLG Plug style
C - Kappa r 15°
TCDCONMS ISO-tolerance class shank diameter
h9
TCTR Thread tolerance class
C2X
TD Thread diameter
20 mm
THFT Thread form type
M
THOD Thread designation
M20x1.5-C2X
TP Thread pitch
1.5 mm
Working process
No working processes available
WT Weight of item
0.181 kg
