C6111001.4037
C6111001.4037
Артикул:
C6111001.4037
В наличии
Характеристики
COATN Coating
--
COMPC Company code
E - Emuge
CXSC Coolant exit style code
0 - Without coolant exit
DIN
ZYL01202105
DRVS Drive size
9 mm
FamilyProducts
MGB-Rek.2A-STEEL/F
FHH Flute helix hand
N - Hand of helix neutral
GRDMFG Grade manufacturers designation
HSSE
GRDPRIO Standard designation of the grade main application
HSS-E
HAND Cutting direction
R - Right
Interface codes
J6 /
ISYC Subclass
301-01 - Thread cutting tap with offset shank
LOC-03 CCFMS Connection code form
21
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0120
LOC-03 DCONMS Diameter
12 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
h$09
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL01202105
Name Identifying order number
C6111001.4037
OAL Overall length
100 mm
PLG Plug style
F
STDNO Standard
DIN 5156
TCDCONMS ISO-tolerance class shank diameter
h9
TCTR Thread tolerance class
X
TD Thread diameter
16.662 mm
TDFR Thread diameter nominal fraction
3/8 in
TDIN Thread diameter nominal inch
0.375 in
THFT Thread form type
G
THOD Thread designation
G3/8-19-X
TP Thread pitch
1.337 mm
TPI Threads per inch
19 1/in
Working process
No working processes available
WT Weight of item
0.09 kg
