Главная Каталог продукции Toolunited 10 301-01 - Thread cutting tap with offset shank C0203700.1141

C0203700.1141

Артикул: C0203700.1141

В наличии

В корзину

Описание

Характеристики

COATN Coating / Покрытие

TIN

COMPC Company code

E - Emuge

CXSC Coolant exit style code

0 - Without coolant exit

DIN

ZYL01202105

DRVS Drive size

9 mm

FamilyProducts

MGB-Rek.2B-Z-TIN

FHH Flute helix hand

N - Hand of helix neutral

GRDMFG Grade manufacturers designation

HSSE

GRDPRIO Standard designation of the grade main application

HSS-E

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

301-01 - Thread cutting tap with offset shank

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0120

LOC-03 DCONMS Diameter

12 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$09

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01202105

Name Identifying order number

C0203700.1141

OAL Overall length

100 mm

PLG Plug style

B - Kappa r 8°

STDNO Standard

DIN 374

TCDCONMS ISO-tolerance class shank diameter

TD Thread diameter

16 mm

THFT Thread form type

LKMF

TP Thread pitch

1.5 mm

Working process

No working processes available

WT Weight of item

0.083 kg
