Главная Каталог продукции Toolunited 10 301-01 - Thread cutting tap with offset shank C0201050.0468

C0201050.0468

Артикул: C0201050.0468

В наличии

В корзину

Описание

Характеристики

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

E - Emuge

CXSC Coolant exit style code

0 - Without coolant exit

Delivery state valid from

10/1/2022

DIN

ZYL02002105

DRVS Drive size

16 mm

FamilyProducts

M/C Tap

FHH Flute helix hand

N - Hand of helix neutral

GRDPRIO Standard designation of the grade main application

HSS-E

HAND Cutting direction

L - Left

Interface codes

J6 /

ISYC Subclass

301-01 - Thread cutting tap with offset shank

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0200

LOC-03 DCONMS Diameter

20 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$09

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL02002105

Name Identifying order number

C0201050.0468

OAL Overall length

140 mm

PLG Plug style

B - Kappa r 8°

STDNO Standard

DIN 374

TCDCONMS ISO-tolerance class shank diameter

TCTR Thread tolerance class

ISO 2/6H

TD Thread diameter

27 mm

THFT Thread form type

THOD Thread designation

M27x1-ISO 2/6H

TP Thread pitch

1 mm

TTPID Tap type identifier

1 - Machine tap

Working process

No working processes available

WT Weight of item

0.338 kg
