Главная Каталог продукции Toolunited 10 301-01 - Thread cutting tap with offset shank C0073700.1058

C0073700.1058

Артикул: C0073700.1058

В наличии

В корзину

Описание

Характеристики

COATN Coating / Покрытие

TIN

COMPC Company code

E - Emuge

CXSC Coolant exit style code

2 - With Coolant exit, radial

DIN

ZYL00902115

DRVS Drive size

7 mm

FamilyProducts

MGB-Rek.2D-Z-IKZN-TIN

FHH Flute helix hand

R - Hand of helix right

GRDMFG Grade manufacturers designation

HSSE

GRDPRIO Standard designation of the grade main application

HSS-E

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

301-01 - Thread cutting tap with offset shank

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0090

LOC-03 DCONMS Diameter

9 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$09

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00902115

Name Identifying order number

C0073700.1058

OAL Overall length

110 mm

PLG Plug style

C - Kappa r 15°

STDNO Standard

DIN 376

TCDCONMS ISO-tolerance class shank diameter

TD Thread diameter

12 mm

THFT Thread form type

LKM

TP Thread pitch

1.75 mm

Working process

No working processes available

WT Weight of item

0.042 kg
