Главная Каталог продукции Toolunited 10 301-00 - Thread cutting tap, forming tap, cutting die unspecified A0181000.5772

A0181000.5772

Артикул: A0181000.5772

В наличии

В корзину

Описание

Характеристики

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating

ohne

COMPC Company code

E - Emuge

CXSC Coolant exit style code

0 - Without coolant exit

DCP Data chip provision

0 - Without data chip

Delivery state valid from

2/1/2024

DIN

ZYL04502105

DRVS Drive size

35 mm

FamilyProducts

machine tap

FHH Flute helix hand

N - Hand of helix neutral

GRDPRIO Standard designation of the grade main application

HSS-E

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

301-00 - Thread cutting tap, forming tap, cutting die unspecified

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0450

LOC-03 DCONMS Diameter

45 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL04502105

Name Identifying order number

A0181000.5772

OAL Overall length

160 mm

PLG Plug style

C - Kappa r 15°

STDNO Standard

DIN 2184-2

TD Thread diameter

60.325 mm

TDFR Thread diameter nominal fraction

2 in

TDIN Thread diameter nominal inch

2 in

TG Taper ratio

1:16

THFT Thread form type

NPT

TP Thread pitch

2.209 mm

TPI Threads per inch

11.5 1/in

TTPID Tap type identifier

1 - Machine tap

Working process

No working processes available

WT Weight of item

1.851 kg
