ICK 116 IC907
ICK 116 IC907
Артикул:
5567273
В наличии
Характеристики
COATN Coating
TiAlN+TiN
COMPC Company code
IS - Iscar
DC Cutting diameter
11.6 mm
DIN
IS-236671093909484
FamilyProducts
Exchangeable DCN Drill Heads, for Cast Iron (ISO K Materials)
GRDMFG Grade manufacturers designation
IC907
ID Technical product number
5567273
Interface codes
J6 / J61
ISO
IS$$236671093909484
ISYC Subclass
203-01 - Replaceable insert with chip flute
LF Functional length
3.94 mm
LOC-03 ISO
IS$$236671093909484
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
IS-236671093909484
LPR Protruding length
6.6 mm
Name Identifying order number
ICK 116 IC907
PL Point length
2.66 mm
SIG Point angle 1st step
140 Degree
Working process
BVB - Drilling
WT Weight of item
0 kg
