Главная Каталог продукции Toolunited 10 202-08 - Lay-down threading insert, triangle shape, three cutting edges, one tooth 270762 6

270762 6

Артикул: 270762 6

В наличии

В корзину

Описание

Характеристики

CB Chip breaker face count

0 - Without chip breaker

COATN Coating

VTX

COMPC Company code

HOG - Hoffmann Group

CRE Spot radius

0.34 mm

DIN

HOG-2200IR6.0ISO0476

FamilyProducts

GARANT Full profile insert 60°, internal, right-hand

GAN Insert rake angle

15 Degree

GRDMFG Grade manufacturers designation

HB7010

IC Inscribed circle diameter

12.7 mm

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

R - Right

INSL Insert length

22 mm

Interface codes

J6 /

ISYC Subclass

202-08 - Lay-down threading insert, triangle shape, three cutting edges, one tooth

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

HOG-2200IR6.0ISO0476

Name Identifying order number

270762 6

NOF Flute count

PDPT Profile depth insert

3.46 mm

PDX Profile distance X

2.5 mm

PDY Profile distance Y

1.8 mm

PNA Profile included angle

60 Degree

S1 Insert thickness total

4.76 mm

STDNO Standard

DIN13

TCE Tipped cutting edge code

THFT Thread form type

TPT Thread profile type

V - Full profile

W1 Insert width

0 mm

Working process

DGI - Thread turning, internal

WT Weight of item

0.003 kg
