FX2.2-E220R5-CE6 WSM33
FX2.2-E220R5-CE6 WSM33
Артикул:
5643471
В наличии
Характеристики
AN Clearance angle major
25 Degree
CB Chip breaker face count
1 - With chip breaker one-side
CBMD Chip breaker manufacturers designation
CE6
COATN Coating
TiAlN+Al2O3+(ZrN)
COMPC Company code
W - Walter
CW Cutting width
2.2 mm
Delivery state valid from
12/1/2023
DIN
W-FX0022007$$E$$$
FamilyProducts
Grooving and parting off – cutting inserts FX
GRDMFG Grade manufacturers designation
WSM33
ID Technical product number
5643471
IFS Insert mounting style code
7 - Prismatic clamping, concave
IH Insert hand
R - Right
INSL Insert length
8.9 mm
Interface codes
J6 / J61
ISO
WR$$FX0022007$$E$$$
ISYC Subclass
202-02 - Insert, one cutting edge for grooving and parting, self clamping
LOC-03 ISO
WR$$FX0022007$$E$$$
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
W-FX0022007$$E$$$
Name Identifying order number
FX2.2-E220R5-CE6 WSM33
NOF Flute count
1
PFS Profile form
2
PSIRR Cutting edge angle major right hand
5 Degree
STDDES Standard designation
FX2.2-E220R5
TCE Tipped cutting edge code
S
Working process
DEA - Outer diameter grooving
WT Weight of item
0.001 kg
