RCMT120400-PR5 WPP20

Артикул: 5522359

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

7 Degree

CBMD Chip breaker manufacturers designation

PR5

COATN Coating

TiCN+Al2O3+(TiN)

COMPC Company code

W - Walter

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

4.4 mm

Delivery state valid from

12/1/2023

DIN

W-RC1204003NB$$00

FamilyProducts

Positive round RCMX

GRDMFG Grade manufacturers designation

WPP20

IC Inscribed circle diameter

12.7 mm

ID Technical product number

5522359

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

N - Neutral

Interface codes

J6 / J441

ISISO ISO property

ISO

WR$$RC1204003NB$$00

ISYC Subclass

201-10 - Round insert

LOC-03 ISO

WR$$RC1204003NB$$00

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

W-RC1204003NB$$00

M M-dimension

12.7 mm

Name Identifying order number

RCMT120400-PR5 WPP20

NameAnsi Identifying order number inch alternative

RCMT43-PR5 WPP20

S Insert thickness

4.76 mm

S1 Insert thickness total

4.76 mm

STDDES Standard designation

RCMT120400

STDDESAnsi Standard designation ANSI

RCMT430

TCE Tipped cutting edge code

TCINS Tolerance class insert

Working process

No working processes available

WT Weight of item

0.006 kg
