7816050

Артикул: 7816050

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

11 Degree

CB Chip breaker face count

1 - With chip breaker one-side

CBMD Chip breaker manufacturers designation

CECC Cutting edge condition code

E - Rounded

COATN Coating

CVD

COMPC Company code

OSG

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

3.4 mm

DIN

OSG-PRC01

FamilyProducts

OSG PRC Inserts XC5040 RPHT10T3M8EN-SM XC5040

GRDMFG Grade manufacturers designation

XC5040

GRDPRIO Standard designation of the grade main application

IC Inscribed circle diameter

10 mm

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-10 - Round insert

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

OSG-PRC01

M M-dimension

10 mm

Name Identifying order number

7816050

S Insert thickness

3.97 mm

STDDES Standard designation

RPHT10T3M8EN-SM

TCINS Tolerance class insert

Working process

No working processes available
