Главная Каталог продукции Toolunited 10 201-09 - Octogonal insert 7816085

7816085

Артикул: 7816085

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

3 Degree

CB Chip breaker face count

2 - With chip breaker on both sides

CBMD Chip breaker manufacturers designation

CECC Cutting edge condition code

E - Rounded

COATN Coating

CVD

COMPC Company code

OSG

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

5.8 mm

DIN

OSG-PAON01

EPSR Insert included angle

135 Degree

FamilyProducts

OSG PAO Inserts OZKU060508ER-SM XC5040

GRDMFG Grade manufacturers designation

XC5040

GRDPRIO Standard designation of the grade main application

IC Inscribed circle diameter

17.1 mm

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

R - Right

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-09 - Octogonal insert

L Cutting edge length

7.08 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

OSG-PAON01

Name Identifying order number

7816085

NOI Insert index count

RE Corner radius

0.8 mm

S Insert thickness

5.56 mm

STDDES Standard designation

OZKU060508ER-SM

TCINS Tolerance class insert

K - Cold formed

Working process

No working processes available
