218.19-160T-04-M08 T25M
218.19-160T-04-M08 T25M
Артикул:
74069544
В наличии
Характеристики
AN Clearance angle major
12 Degree
CEMR Cutting edge major radius
16 mm
COMPC Company code
SO - SECO Tools
Delivery state valid from
3/14/2020
DIN
SO-SO 218 19-160
FamilyProducts
218.19-160T-04-M08 T25M
GRDMFG Grade manufacturers designation
T25M
IC Inscribed circle diameter
11.18 mm
ID Technical product number
74069544
IH Insert hand
N - Neutral
Interface codes
J6 / J441
ISISO ISO property
0
ISO
SO$$218 191600412N
ISYC Subclass
201-07 - Trigon insert
LOC-03 ISO
SO$$218 191600412N
LOC-03-Connection-codes
J6 / J441 - connection code machine end
LOC-03-DIN
SO-SO 218 19-160
Name Identifying order number
218.19-160T-04-M08 T25M
NOI Insert index count
3
RE Corner radius
1.2 mm
S Insert thickness
4.76 mm
Working process
No working processes available
WT Weight of item
0.1 kg
