Главная Каталог продукции Toolunited 10 201-04 - Rectangular insert HSM90S APCR 220730R-P IC08

HSM90S APCR 220730R-P IC08

Артикул: 3321533

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

11 Degree

BS Wiper edge length

3 mm

COATN Coating

ohne

COMPC Company code

IS - Iscar

D1 Fixing hole diameter

9 mm

FamilyProducts

Super Positive Inserts with a Polished Rake for Machining Aluminum at High Rotation Speed

GRDMFG Grade manufacturers designation

IC08

IC Inscribed circle diameter

12.9 mm

ID Technical product number

3321533

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

R - Right

Interface codes

ISISO ISO property

ISYC Subclass

201-04 - Rectangular insert

KRINS Cutting edge angle major

90 Degree

L Cutting edge length

29 mm

LE Cutting edge effective length

29 mm

Name Identifying order number

HSM90S APCR 220730R-P IC08

RE Corner radius

3 mm

S Insert thickness

6.7 mm

W1 Insert width

12.9 mm

Working process

No working processes available

WT Weight of item

0.01 kg
