Главная Каталог продукции Toolunited 10 201-02 - Square insert SPMT060304-F55 WXP45

SPMT060304-F55 WXP45

Артикул: 5036815

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

11 Degree

CBMD Chip breaker manufacturers designation

F55

CECC Cutting edge condition code

S - Chamfered and rounded

COMPC Company code

W - Walter

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

2.8 mm

Delivery state valid from

12/1/2023

DIN

W-SP0603043NB$$04

EPSR Insert included angle

90 Degree

FamilyProducts

Positive square SPMT

GRDMFG Grade manufacturers designation

WXP45

IC Inscribed circle diameter

6.35 mm

ID Technical product number

5036815

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

N - Neutral

Interface codes

J6 / J441

ISISO ISO property

ISO

WR$$SP0603043NB$$04

ISYC Subclass

201-02 - Square insert

L Cutting edge length

6.35 mm

LOC-03 ISO

WR$$SP0603043NB$$04

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

W-SP0603043NB$$04

Name Identifying order number

SPMT060304-F55 WXP45

NameAnsi Identifying order number inch alternative

SPMT221-F55 WXP45

NOI Insert index count

RE Corner radius

0.4 mm

S Insert thickness

3.18 mm

S1 Insert thickness total

3.18 mm

STDDES Standard designation

SPMT060304

STDDESAnsi Standard designation ANSI

SPMT221

TCE Tipped cutting edge code

TCINS Tolerance class insert

Working process

FPL - Face milling

WT Weight of item

0.001 kg
