SNMM250732-NRR WPP20S

Артикул: 6160631

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

0 Degree

CB Chip breaker face count

1 - With chip breaker one-side

CBMD Chip breaker manufacturers designation

NRR

COATN Coating

TiCN+Al2O3+(TiCN)

COMPC Company code

W - Walter

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

9.12 mm

Delivery state valid from

12/1/2023

DIN

SN2507322N

EPSR Insert included angle

90 Degree

FamilyProducts

Negative square SNMM

GRDMFG Grade manufacturers designation

WPP20S

IC Inscribed circle diameter

25.4 mm

ID Technical product number

6160631

IFS Insert mounting style code

2 - With cylindrical bore

IH Insert hand

N - Neutral

Interface codes

J6 / J441

ISISO ISO property

ISO

ISO$SN2507322NB$$32

ISYC Subclass

201-02 - Square insert

L Cutting edge length

25.4 mm

LOC-03 ISO

ISO$SN2507322NB$$32

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

SN2507322N

MIID Master insert identification

SNMM250732 WPP20S

Name Identifying order number

SNMM250732-NRR WPP20S

NameAnsi Identifying order number inch alternative

SNMM858-NRR WPP20S

NOI Insert index count

RE Corner radius

3.2 mm

S Insert thickness

7.9375 mm

S1 Insert thickness total

7.9375 mm

STDDES Standard designation

SNMM250732

STDDESAnsi Standard designation ANSI

SNMM858

TCE Tipped cutting edge code

TCINS Tolerance class insert

Working process

No working processes available

WT Weight of item

0.059 kg
