SCMT09T308-PS5 WPP20

Артикул: 5200023

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

7 Degree

CB Chip breaker face count

1 - With chip breaker one-side

CBMD Chip breaker manufacturers designation

PS5

COATN Coating

TiCN+Al2O3+(TiN)

COMPC Company code

W - Walter

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

4.4 mm

Delivery state valid from

12/1/2023

DIN

SC09T3083N

EPSR Insert included angle

90 Degree

FamilyProducts

Positive square SCMT

GRDMFG Grade manufacturers designation

WPP20

IC Inscribed circle diameter

9.525 mm

ID Technical product number

5200023

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

N - Neutral

Interface codes

J6 / J441

ISISO ISO property

ISO

ISO$SC09T3083NB$$08

ISYC Subclass

201-02 - Square insert

L Cutting edge length

9.525 mm

LOC-03 ISO

ISO$SC09T3083NB$$08

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

SC09T3083N

MIID Master insert identification

SCMT09T308 WPP20

Name Identifying order number

SCMT09T308-PS5 WPP20

NameAnsi Identifying order number inch alternative

SCMT3(2.5)2-PS5 WPP20

NOI Insert index count

RE Corner radius

0.8 mm

S Insert thickness

3.96875 mm

S1 Insert thickness total

3.96875 mm

STDDES Standard designation

SCMT09T308

STDDESAnsi Standard designation ANSI

SCMT32.52

TCE Tipped cutting edge code

TCINS Tolerance class insert

Working process

No working processes available

WT Weight of item

0.004 kg
