SCMT09T308-E47 WSM10

Артикул: 6118400

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

7 Degree

CBMD Chip breaker manufacturers designation

E47

COATN Coating

TiAlN+Al2O3+(ZrN)

COMPC Company code

W - Walter

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

4.4 mm

Delivery state valid from

12/1/2023

DIN

W-BE09T3$$3RB$$$$

EPSR Insert included angle

90 Degree

FamilyProducts

Positive square SCMT

GRDMFG Grade manufacturers designation

WSM10

IC Inscribed circle diameter

9.525 mm

ID Technical product number

6118400

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

R - Right

Interface codes

J6 / J441

ISISO ISO property

ISO

WR$$BE09T3$$3RB$$$$

ISYC Subclass

201-02 - Square insert

L Cutting edge length

9.525 mm

LOC-03 ISO

WR$$BE09T3$$3RB$$$$

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

W-BE09T3$$3RB$$$$

Name Identifying order number

SCMT09T308-E47 WSM10

NameAnsi Identifying order number inch alternative

SCMT3(2.5)2-E47 WSM10

RE Corner radius

0.8 mm

S Insert thickness

3.97 mm

S1 Insert thickness total

3.97 mm

STDDES Standard designation

SCMT09T308

STDDESAnsi Standard designation ANSI

SCMT32.52

TCE Tipped cutting edge code

TCINS Tolerance class insert

Working process

BVB - Drilling

WT Weight of item

0.004 kg
