UNLU0603M0TR IN2505
UNLU0603M0TR IN2505
Артикул:
5812830
В наличии
Характеристики
AN Clearance angle major
0 Degree
CB Chip breaker face count
2 - With chip breaker on both sides
COATN Coating
TiAIN+TiN
COMPC Company code
IL - Ingersoll
D1 Fixing hole diameter
3.3 mm
Delivery state
LL - Stock limited
DIN
UN0603 5N
FamilyProducts
insert, four-edged, semi positive geometry
GRD2ND Standard designation of the grade 2nd application
M15-M35
GRD3RD Standard designation of the grade 3rd application
K20-K40
GRDMFG Grade manufacturers designation
IN2505
GRDPRIO Standard designation of the grade main application
P15-P30
IC Inscribed circle diameter
6.39 mm
ID Technical product number
5812830
IFS Insert mounting style code
5 - Special production, e.g. trough clamping
IH Insert hand
R - Right
Interface codes
J6 /
ISISO ISO property
0
ISYC Subclass
201-00 - Regular Insert unspecified
L Cutting edge length
1 mm
LE Cutting edge effective length
1 mm
LOC-03-Connection-codes
J6 / J441 - connection code machine end
LOC-03-DIN
UN0603 5N
Name Identifying order number
UNLU0603M0TR IN2505
S Insert thickness
3.73 mm
S1 Insert thickness total
3.73 mm
STDDES Standard designation
UNLU0603M0TR
TCINS Tolerance class insert
L
W1 Insert width
6.39 mm
Working process
No working processes available
