7043303000
7043303000
Артикул:
7043303000
В наличии
Характеристики
CBMD Chip breaker manufacturers designation
-XU
CECC Cutting edge condition code
E - Rounded
COATN Coating / Покрытие
CTCK110
COMPC Company code
CE - Ceratizit
D1 Fixing hole diameter
5.16 mm
EPSR Insert included angle
80 Degree
FamilyProducts
HM-DREHWENDEPLATTE
GRDPRIO Standard designation of the grade main application
HC-K10
IC Inscribed circle diameter
12.7 mm
IH Insert hand
N - Neutral
Interface codes
/
ISISO ISO property
1
ISYC Subclass
201-03 - Rhombic insert
L Cutting edge length
12.9 mm
Name Identifying order number
7043303000
RE Corner radius
0.8 mm
S Insert thickness
6.35 mm
TCINS Tolerance class insert
M
Working process
No working processes available
