VCGW 160408TN-020D_B3 CTBK104

Артикул: 11928803

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

7 Degree

BN Face land width

0.2 mm

CB Chip breaker face count

0 - Without chip breaker

CECC Cutting edge condition code

T - Chamfered

COMPC Company code

CE - Ceratizit

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

4.4 mm

DIN

VC1604083N

EPSR Insert included angle

35 Degree

FamilyProducts

turning insert VCGW-020D

GB Face land angle

20 Degree

GRD2ND Standard designation of the grade 2nd application

BH-H25

GRDMFG Grade manufacturers designation

CTBK104

GRDPRIO Standard designation of the grade main application

BH-K10

IC Inscribed circle diameter

9.52 mm

ID Technical product number

11928803

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-03 - Rhombic insert

L Cutting edge length

16.6 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

VC1604083N

Name Identifying order number

VCGW 160408TN-020D B3 CTBK104

RE Corner radius

0.8 mm

S Insert thickness

4.76 mm

S1 Insert thickness total

4.76 mm

STDDES Standard designation

VCGW160408TN

STDDESAnsi Standard designation ANSI

VCGW332TN

TCINS Tolerance class insert

Working process

DDI - Internal turning
