DNMG150408 KT150
DNMG150408 KT150
Артикул:
DNMG150408 KT150
В наличии
Характеристики
CB Chip breaker face count
2 - With chip breaker on both sides
COMPC Company code
KH - Kennametal
CSP Coolant supply property
0 - Without coolant supply
D1 Fixing hole diameter
5.16 mm
Delivery state
LH - Stocked
DIN
DN1504 2N
EPSR Insert included angle
55 Degree
FamilyProducts
Kenloc Insert
GRDMFG Grade manufacturers designation
KT150
IC Inscribed circle diameter
12.7 mm
IFS Insert mounting style code
2 - With cylindrical bore
IH Insert hand
N - Neutral
Interface codes
J6 /
ISISO ISO property
0
ISYC Subclass
201-03 - Rhombic insert
L Cutting edge length
15.5 mm
LOC-03-Connection-codes
J6 / J441 - connection code machine end
LOC-03-DIN
DN1504 2N
Name Identifying order number
DNMG150408 KT150
RE Corner radius
0.8 mm
S Insert thickness
4.76 mm
S1 Insert thickness total
4.76 mm
STDDES Standard designation
DNMG150408
STDDESAnsi Standard designation ANSI
DNMG432
TCINS Tolerance class insert
M
Working process
DDA - External turning
Главный задний угол (AN) / Clearance angle major (AN)
0 Degree
