CPMT1205ZPEN-M2 F7030

Артикул: CPMT1205ZPEN-M2 F7030

В наличии

В корзину

Описание

Характеристики

AS Clearance angle wiper edge

11 Degree

BS Wiper edge length

1.4 mm

CB Chip breaker face count

1 - With chip breaker one-side

CBMD Chip breaker manufacturers designation

COATN Coating / Покрытие

TiN-Al2O3

COMPC Company code

MI - Mitsubishi Materials

CSP Coolant supply property

0 - Without coolant supply

Delivery state valid from

4/1/2022

DIN

CP1205ZP3N

EPSR Insert included angle

80 Degree

FamilyProducts

insert for milling

GRD2ND Standard designation of the grade 2nd application

HC-M10

GRD3RD Standard designation of the grade 3rd application

HC-P30

GRDMFG Grade manufacturers designation

F7030

GRDPRIO Standard designation of the grade main application

HC-P10

IC Inscribed circle diameter

12.7 mm

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-03 - Rhombic insert

L Cutting edge length

12.7 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

CP1205ZP3N

Materials

Name Identifying order number

CPMT1205ZPEN-M2 F7030

RE Corner radius

0.8 mm

S Insert thickness

5.56 mm

S1 Insert thickness total

5.56 mm

STDDES Standard designation

CPMT1205ZPEN

TCINS Tolerance class insert

Working process

F - Milling,FEC - Square shoulder milling,FPL - Face milling,FPR - Profile milling,FZI - Circular milling

Главный задний угол (AN) / Clearance angle major (AN)

11 Degree
