CNMX 120716-M4PW IC9150

Артикул: 5507344

В наличии

В корзину

Описание

Характеристики

CBMD Chip breaker manufacturers designation

M4PW

COMPC Company code

IS - Iscar

CSP Coolant supply property

0 - Without coolant supply

Delivery state valid from

12/30/2017

DIN

CN1207162N

EPSR Insert included angle

80 Degree

FamilyProducts

Double-Sided 80° Rhombic Insert

GRDMFG Grade manufacturers designation

IC9150

IC Inscribed circle diameter

12.7 mm

ID Technical product number

5507344

IFS Insert mounting style code

2 - With cylindrical bore

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-03 - Rhombic insert

L Cutting edge length

12.9 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

CN1207162N

Name Identifying order number

CNMX 120716-M4PW IC9150

NameAnsi Identifying order number inch alternative

CNMX 454-M4PW IC9150

RE Corner radius

1.6 mm

S Insert thickness

6.75 mm

S1 Insert thickness total

6.75 mm

STDDES Standard designation

CNMX120716

STDDESAnsi Standard designation ANSI

CNMX 454

TCINS Tolerance class insert

Working process

DDA - External turning

Главный задний угол (AN) / Clearance angle major (AN)

0 Degree
