CNMX 120708-M4MW IC830

Артикул: CNMX 120708-M4MW IC830

В наличии

В корзину

Описание

Характеристики

CBMD Chip breaker manufacturers designation

M4MW

COATN Coating / Покрытие

AlTiN+TiN

COMPC Company code

IS - Iscar

CSP Coolant supply property

0 - Without coolant supply

Delivery state valid from

8/7/2014

DIN

CN1207082N

EPSR Insert included angle

80 Degree

FamilyProducts

Double-Sided 80° Rhombic Insert

GRD2ND Standard designation of the grade 2nd application

HC-S15

GRDMFG Grade manufacturers designation

IC830

GRDPRIO Standard designation of the grade main application

HC-P20

IC Inscribed circle diameter

12.7 mm

IFS Insert mounting style code

2 - With cylindrical bore

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-03 - Rhombic insert

L Cutting edge length

12.9 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

CN1207082N

Name Identifying order number

CNMX 120708-M4MW IC830

RE Corner radius

0.8 mm

S Insert thickness

6.75 mm

S1 Insert thickness total

6.75 mm

STDDES Standard designation

CNMX120708

STDDESAnsi Standard designation ANSI

CNMX 452

TCINS Tolerance class insert

Working process

DDA - External turning

Главный задний угол (AN) / Clearance angle major (AN)

0 Degree
