CNMN 090316TN-020D TA120

Артикул: CNMN 090316TN-020D TA120

В наличии

В корзину

Описание

Характеристики

CB Chip breaker face count

0 - Without chip breaker

CECC Cutting edge condition code

T - Chamfered

COMPC Company code

CE - Ceratizit

CSP Coolant supply property

0 - Without coolant supply

DIN

CN0903161N

EPSR Insert included angle

80 Degree

FamilyProducts

CBN turning insert

GRDMFG Grade manufacturers designation

TA120

GRDPRIO Standard designation of the grade main application

IC Inscribed circle diameter

9.52 mm

IFS Insert mounting style code

1 - Without bore

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-03 - Rhombic insert

L Cutting edge length

9.7 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

CN0903161N

Name Identifying order number

CNMN 090316TN-020D TA120

RE Corner radius

1.6 mm

S Insert thickness

3.18 mm

S1 Insert thickness total

3.18 mm

STDDES Standard designation

CNMN090316TN

STDDESAnsi Standard designation ANSI

CNMN324TN

TCINS Tolerance class insert

Working process

No working processes available

Главный задний угол (AN) / Clearance angle major (AN)

0 Degree
