CNMG 090308-TF IC8250

Артикул: 5550241

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

0 Degree

CB Chip breaker face count

2 - With chip breaker on both sides

CBMD Chip breaker manufacturers designation

COATN Coating / Покрытие

TiN-TiCN

COMPC Company code

IS - Iscar

CSP Coolant supply property

0 - Without coolant supply

Delivery state valid from

2/1/2012

DIN

CN0903082N

EPSR Insert included angle

80 Degree

FamilyProducts

CNMG 090308-TF IC8250

GAN Insert rake angle

13 Degree

GRD2ND Standard designation of the grade 2nd application

HC-P01

GRD3RD Standard designation of the grade 3rd application

HC-K15

GRDMFG Grade manufacturers designation

IC8250

GRDPRIO Standard designation of the grade main application

HC-P35

IC Inscribed circle diameter

9.525 mm

ID Technical product number

5550241

IFS Insert mounting style code

2 - With cylindrical bore

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-03 - Rhombic insert

L Cutting edge length

9.7 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

CN0903082N

Materials

Name Identifying order number

CNMG 090308-TF IC8250

NameAnsi Identifying order number inch alternative

CNMG 322-TF IC8250

RE Corner radius

0.8 mm

S Insert thickness

3.18 mm

S1 Insert thickness total

3.18 mm

STDDES Standard designation

CNMG090308

STDDESAnsi Standard designation ANSI

CNMG 322

TCINS Tolerance class insert

Working process

No working processes available
