CNGG120408NGHAC503U

Артикул: 224887

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

0 Degree

CB Chip breaker face count

2 - With chip breaker on both sides

CBMD Chip breaker manufacturers designation

NGH

CECC Cutting edge condition code

E - Rounded

COATN Coating / Покрытие

Super ZX

COMPC Company code

SU - Sumitomo

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

5.16 mm

DIN

CN1204082N

EPSR Insert included angle

80 Degree

FamilyProducts

Sumitomo Carbide Insert for Turning

GRD2ND Standard designation of the grade 2nd application

HC-H01

GRD3RD Standard designation of the grade 3rd application

HC-H01

GRDMFG Grade manufacturers designation

AC503U

GRDPRIO Standard designation of the grade main application

HC-H05

IC Inscribed circle diameter

12.7 mm

ID Technical product number

224887

IFS Insert mounting style code

2 - With cylindrical bore

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-03 - Rhombic insert

L Cutting edge length

12.9 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

CN1204082N

MIID Master insert identification

CNGG120408 AC503U

Name Identifying order number

CNGG120408NGHAC503U

RE Corner radius

0.8 mm

S Insert thickness

4.76 mm

S1 Insert thickness total

4.76 mm

STDDES Standard designation

CNGG120408

STDDESAnsi Standard designation ANSI

CNGG432

TCE Tipped cutting edge code

TCINS Tolerance class insert

Working process

DDA - External turning
