CCMT09T302NSUAC830P

Артикул: 208441

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

7 Degree

CB Chip breaker face count

1 - With chip breaker one-side

CBMD Chip breaker manufacturers designation

NSU

CECC Cutting edge condition code

E - Rounded

COATN Coating / Покрытие

Super FF

COMPC Company code

SU - Sumitomo

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

4.4 mm

DIN

CC09T3023N

EPSR Insert included angle

80 Degree

FamilyProducts

insert, solid carbide, CCMT-NSU

GAN Insert rake angle

8 Degree

GRD2ND Standard designation of the grade 2nd application

HC-P25

GRD3RD Standard designation of the grade 3rd application

HC-P35

GRDMFG Grade manufacturers designation

AC830P

GRDPRIO Standard designation of the grade main application

HC-P30

IC Inscribed circle diameter

9.525 mm

ID Technical product number

208441

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-03 - Rhombic insert

L Cutting edge length

9.67 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

CC09T3023N

MIID Master insert identification

CCMT09T302 AC830P

Name Identifying order number

CCMT09T302NSUAC830P

RE Corner radius

0.2 mm

S Insert thickness

3.97 mm

S1 Insert thickness total

3.962 mm

STDDES Standard designation

CCMT09T302

TCE Tipped cutting edge code

TCINS Tolerance class insert

Working process

DDA - External turning,DDI - Internal turning
