CCGT09T304LW20 NS530

Артикул: CCGT09T304LW20 NS530

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

7 Degree

ANN Clearance angle minor

0 Degree

CB Chip breaker face count

1 - With chip breaker one-side

CBMD Chip breaker manufacturers designation

W20

COMPC Company code

TT - Tungaloy

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

4.4 mm

Delivery state valid from

8/24/2006

DIN

CC09T3 3L

EPSR Insert included angle

80 Degree

FamilyProducts

Positive turning inserts cermet

GAN Insert rake angle

0 Degree

GRDMFG Grade manufacturers designation

NS530

GRDPRIO Standard designation of the grade main application

HT-P15

IC Inscribed circle diameter

9.525 mm

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

L - Left

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-03 - Rhombic insert

L Cutting edge length

9.7 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

CC09T3 3L

Materials

P,K

Name Identifying order number

CCGT09T304LW20 NS530

RE Corner radius

0.4 mm

S Insert thickness

3.97 mm

S1 Insert thickness total

3.97 mm

STDDES Standard designation

CCGT09T304

STDDESAnsi Standard designation ANSI

CCGT32.51

TCINS Tolerance class insert

Working process

DDA - External turning,DDI - Internal turning
