CCGT09T301MNSIAC610M

Артикул: 215653

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

7 Degree

CB Chip breaker face count

1 - With chip breaker one-side

CBMD Chip breaker manufacturers designation

NSI

CECC Cutting edge condition code

E - Rounded

COATN Coating / Покрытие

Super FF

COMPC Company code

SU - Sumitomo

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

4.4 mm

DIN

CC09T3013N

EPSR Insert included angle

80 Degree

FamilyProducts

Sumitomo Carbide Insert for Turning

GRD2ND Standard designation of the grade 2nd application

HC-M05

GRD3RD Standard designation of the grade 3rd application

HC-M15

GRDMFG Grade manufacturers designation

AC610M

GRDPRIO Standard designation of the grade main application

HC-M10

IC Inscribed circle diameter

9.525 mm

ID Technical product number

215653

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-03 - Rhombic insert

L Cutting edge length

9.67 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

CC09T3013N

MIID Master insert identification

CCGT09T301 AC610M

Name Identifying order number

CCGT09T301MNSIAC610M

RE Corner radius

0.1 mm

S Insert thickness

3.97 mm

S1 Insert thickness total

3.97 mm

STDDES Standard designation

CCGT09T301

TCE Tipped cutting edge code

TCINS Tolerance class insert

Working process

DDA - External turning,DDI - Internal turning
