CCGT060208F-1MED YCD421

Артикул: CCGT060208F-1MED YCD421

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

7 Degree

CECC Cutting edge condition code

F - Sharpedged

COATN Coating / Покрытие

ohne

COMPC Company code

ZCC - ZCC Cutting Tools

D1 Fixing hole diameter

2.8 mm

Delivery state

SF - Made to order

DIN

CC0602023N

EPSR Insert included angle

80 Degree

FamilyProducts

CC** positive insert

GRDMFG Grade manufacturers designation

YCD421

GRDPRIO Standard designation of the grade main application

N01-10

IC Inscribed circle diameter

6.35 mm

ID Identifying order number

CCGT060208F-1MED YCD421

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-03 - Rhombic insert

L Cutting edge length

6.4 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

CC0602023N

MIID Master insert identification

CCGT060208 YCD421

RE Corner radius

0.8 mm

S Insert thickness

2.38 mm

S1 Insert thickness total

2.38 mm

STDDES Standard designation

CCGT060208

STDDESAnsi Standard designation ANSI

CCGT21.52

TCE Tipped cutting edge code

TCINS Tolerance class insert

Working process

No working processes available
