R114.1430.5.00 TN35

Артикул: R1141430500TN35

В наличии

В корзину

Описание

Характеристики

COMPC Company code

HORN - Paul Horn

CW Cutting width

3 mm

Delivery state valid from

1/15/2014

DIN

HORN-11400

FamilyProducts

Insert

GRDMFG Grade manufacturers designation

TN35

ID Technical product number

R1141430500TN35

IH Insert hand

R - Right

Interface codes

J6 /

ISYC Subclass

202-02 - Insert, one cutting edge for grooving and parting, self clamping

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

HORN-11400

Name Identifying order number

R114.1430.5.00 TN35

NOF Flute count

PDPT Profile depth insert

6 mm

PFS Profile form

REL Corner radius left hand

0.2 mm

RER Corner radius right hand

0.2 mm

TTP Thread type

Working process

DEA - Outer diameter grooving,DEI - Grooving
