R111.3067.02 TH35

Артикул: R111306702TH35

В наличии

В корзину

Описание

Характеристики

COMPC Company code

HORN - Paul Horn

Delivery state valid from

4/2/2013

DIN

HORN-11100

FamilyProducts

Insert

GRDMFG Grade manufacturers designation

TH35

ID Technical product number

R111306702TH35

IH Insert hand

R - Right

INSL Insert length

10.7 mm

Interface codes

J6 /

ISYC Subclass

202-02 - Insert, one cutting edge for grooving and parting, self clamping

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

HORN-11100

Name Identifying order number

R111.3067.02 TH35

NOF Flute count

PDPT Profile depth insert

2.3 mm

PFS Profile form

REL Corner radius left hand

0.2 mm

RER Corner radius right hand

0.2 mm

S1 Insert thickness total

8 mm

TTP Thread type

W1 Insert width

4.15 mm

Working process

DEI - Grooving
