LS111.1867.R4 TH35
LS111.1867.R4 TH35
Артикул:
LS1111867R4TH35
В наличии
Характеристики
COMPC Company code
HORN - Paul Horn
Delivery state valid from
4/2/2013
DIN
HORN-11100
FamilyProducts
Insert
GRDMFG Grade manufacturers designation
TH35
ID Technical product number
LS1111867R4TH35
IH Insert hand
L - Left
INSL Insert length
10.7 mm
Interface codes
J6 /
ISYC Subclass
202-02 - Insert, one cutting edge for grooving and parting, self clamping
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
HORN-11100
Name Identifying order number
LS111.1867.R4 TH35
NOF Flute count
1
PFS Profile form
1
REL Corner radius left hand
0.4 mm
RER Corner radius right hand
0.4 mm
S1 Insert thickness total
8 mm
TTP Thread type
V
W1 Insert width
3.95 mm
Working process
DEI - Grooving,DFI - Internal form turning,DPI - Profiling internal
