GX24-4R3.00N-F3 CTD4110

Артикул: GX24-4R3.00N-F3 CTD4110

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

7 Degree

CB Chip breaker face count

1 - With chip breaker one-side

CBMD Chip breaker manufacturers designation

COMPC Company code

CE - Ceratizit

CRE Spot radius

3 mm

CW Cutting width

6 mm

CWLD Cutting width lower deviation

0.03 mm

CWUD Cutting width upper deviation

0.03 mm

D1 Fixing hole diameter

0 mm

FamilyProducts

PKD parting and grooving insert (formerly S010)

GRDMFG Grade manufacturers designation

CTD4110

GRDPRIO Standard designation of the grade main application

DP-K05

IFS Insert mounting style code

7 - Prismatic clamping, concave

IH Insert hand

N - Neutral

INSL Insert length

25.57 mm

Interface codes

ISYC Subclass

202-02 - Insert, one cutting edge for grooving and parting, self clamping

Name Identifying order number

GX24-4R3.00N-F3 CTD4110

NOF Flute count

NT Tooth count

PDPT Profile depth insert

4 mm

PFS Profile form

W1 Insert width

4.3 mm

Working process

No working processes available
