ER317I08U00GUN KCU25

Артикул: 5533371

В наличии

В корзину

Описание

Характеристики

CB Chip breaker face count

0 - Without chip breaker

COMPC Company code

KH - Kennametal

CRE Spot radius

4.03 mm

CW Cutting width

8.052 mm

CWLD Cutting width lower deviation

0.075 mm

CWUD Cutting width upper deviation

0.075 mm

Delivery state valid from

3/2/2016

DIN

KH-KGM-8

FamilyProducts

GUN Full Radius Precision Molded • Inch

GRDMFG Grade manufacturers designation

KCU25

IC Inscribed circle diameter

8.052 mm

ID Technical product number

5533371

IH Insert hand

N - Neutral

INSL Insert length

17.5 mm

Interface codes

J6 /

ISYC Subclass

202-02 - Insert, one cutting edge for grooving and parting, self clamping

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

KH-KGM-8

Name Identifying order number

ER317I08U00GUN KCU25

NOF Flute count

NT Tooth count

PFS Profile form

TPT Thread profile type

V - Full profile

Working process

DEA - Outer diameter grooving,DEI - Grooving,DDA - External turning,DDI - Internal turning,DSS - Face grooving
