EC040M04R06CL02 KCU25

Артикул: 5533515

В наличии

В корзину

Описание

Характеристики

CB Chip breaker face count

0 - Without chip breaker

COMPC Company code

KH - Kennametal

CW Cutting width

4 mm

CWLD Cutting width lower deviation

0.075 mm

CWUD Cutting width upper deviation

0.075 mm

Delivery state valid from

3/2/2016

DIN

KH-KGM-4

FamilyProducts

CL Precision Molded • Metric

GRDMFG Grade manufacturers designation

KCU25

IC Inscribed circle diameter

4 mm

ID Technical product number

5533515

IH Insert hand

R - Right

INSL Insert length

10.19 mm

Interface codes

J6 /

ISYC Subclass

202-02 - Insert, one cutting edge for grooving and parting, self clamping

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

KH-KGM-4

Name Identifying order number

EC040M04R06CL02 KCU25

NOF Flute count

NT Tooth count

PFS Profile form

PSIRR Cutting edge angle major right hand

6 Degree

REL Corner radius left hand

0.2 mm

TPT Thread profile type

V - Full profile

Working process

DEA - Outer diameter grooving,DEI - Grooving,DSS - Face grooving
