Главная Каталог продукции Токарная обработка Обработка канавок и отрезка Пластины для обработки канавок и отрезки 12356913085

12356913085

Артикул: 12356913085

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

7 Degree

COATN Coating / Покрытие

Plasma-CVD

COMPC Company code

WI - Widia

CW Cutting width

3.1 mm

CWLD Cutting width lower deviation

-0.05 mm

CWUD Cutting width upper deviation

0.05 mm

Delivery state valid from

12.4 €

DIN

WI-123569130

FamilyProducts

insert for grooving and parting

GRD2ND Standard designation of the grade 2nd application

HC-M30

GRDMFG Grade manufacturers designation

TPC35

GRDPRIO Standard designation of the grade main application

HC-P35

ID Technical product number

12356913085

IH Insert hand

N - Neutral

INSL Insert length

20 mm

Interface codes

J6 /

ISYC Subclass

202-02 - Insert, one cutting edge for grooving and parting, self clamping

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

WI-123569130

Name Identifying order number

12356913085

NOF Flute count

PFS Profile form

PSIRL Cutting edge angle major left hand

0 Degree

PSIRR Cutting edge angle major right hand

0 Degree

REL Corner radius left hand

0.2 mm

RER Corner radius right hand

0.2 mm

Working process

No working processes available
