12356753043

Артикул: 12356753043

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

7 Degree

COMPC Company code

WI - Widia

CW Cutting width

3 mm

CWLD Cutting width lower deviation

0.05 mm

CWUD Cutting width upper deviation

0.15 mm

Delivery state valid from

11.1 €

DIN

WI-123567530

FamilyProducts

insert for grooving and parting

GRD2ND Standard designation of the grade 2nd application

HC-M30

GRDMFG Grade manufacturers designation

TN35

GRDPRIO Standard designation of the grade main application

HC-P30

ID Technical product number

12356753043

IH Insert hand

N - Neutral

Interface codes

J6 /

ISYC Subclass

202-02 - Insert, one cutting edge for grooving and parting, self clamping

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

WI-123567530

Name Identifying order number

12356753043

NOF Flute count

PFS Profile form

PSIRL Cutting edge angle major left hand

0 Degree

PSIRR Cutting edge angle major right hand

0 Degree

REL Corner radius left hand

0.2 mm

RER Corner radius right hand

0.2 mm

Working process

No working processes available
