Главная Каталог продукции Sandvik Coromant 305-08 - Boring head for adjustable units EH25-R824XS10-013

EH25-R824XS10-013

EH25-R824XS10-013 EH25-R824XS10-013 EH25-R824XS10-013 EH25-R824XS10-013

EH25-R824XS10-013

Sandvik Coromant
Артикул: 6764255
В наличии
В корзину
Описание
Характеристики
ADJBY (Adjustment property)
1 - Radial adjustment possible
ADJIN (Adjustment increment axial)
0.001 mm
ADJRGA (Adjustment range axial)
1.5 mm
BMC (Body material code)
S - Solid steel
CNSC (Coolant entry style code)
1 - With Coolant entry, axial concentric
CXSC (Coolant exit style code)
1 - With Coolant exit, axial concentric
CXSC (Coolant exit style code) / Тип подвода СОЖ
1 - With Coolant exit, axial concentric
Delivery state
LH - Stocked
Delivery state valid from
12/1/2023
DIN
SAC02500415
HAND (Cutting direction)
R - Right
Interface codes
J6 / J61
ISO
SAC04A0250$$$$
LB (Body length)
38 mm
LOC-01 ISO
ZYL54G1000****
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
ZYL01005415
LOC-02 ISO
ZYL54R3937****
LOC-02-Connection-codes
J4 / J431 - Workpiece end
LOC-02-DIN
ZYL03935435
LOC-03 ISO
SAC04A0250$$$$
LOC-03 (CCFMS Connection code form)
04
LOC-03 (CCSMS Connection code style)
5 Shaft in machine direction or hole in workpiece direction
LOC-03 (CCTMS Connection code type)
SAC Screw mounting SANDVIK Coromant
LOC-03 (CCUMS Connection code unit base)
1 Metric with coolant
LOC-03 (CZCMS Connection size code)
0250
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SAC02500415
Working process
BAB - Open by boring
WT (Weight of item)
0.33 kg
