Главная Инструменты 311-00 - Solid reamer unspecified 452.R-0953-025A0-C H10F

452.R-0953-025A0-C H10F

452.R-0953-025A0-C H10F 452.R-0953-025A0-C H10F 452.R-0953-025A0-C H10F

452.R-0953-025A0-C H10F

SV - Sandvik-Coromant
Артикул: 6012064
В наличии
0 ₽
В корзину
Описание
Характеристики
APMX (Depth of cut maximum)
50.8 mm
BMC (Body material code)
H - Solid carbide
CNSC (Coolant entry style code)
0 - Without coolant entry
COATN (Coating)
Constant Constant
CXSC (Coolant exit style code)
0 - Without coolant exit
CXSC (Coolant exit style code) / Тип подвода СОЖ
0 - Without coolant exit
DC (Cutting diameter minimum)
9.527 mm
DCP (Data chip provision)
0 - Without data chip
Delivery state
NL - Discontinued
Delivery state valid from
12/1/2023
DIN
ZYL03750125
FHA (Flute helix angle)
0 Degree
FHH (Flute helix hand)
N - Hand of helix neutral
GEP (Guide element property)
1 - With guide element
GRDMFG (Grade manufacturers designation)
H10F
GRDPRIO (Standard designation of the grade main application)
HF
HAND (Cutting direction)
R - Right
Interface codes
J6 / J61
ISO
ZYL01R3750$$$$
LF (Functional length)
81.41 mm
LOC-03 ISO
ZYL01R3750$$$$
LOC-03 (CCFMS Connection code form)
01
LOC-03 (CCSMS Connection code style)
5 Shaft in machine direction or hole in workpiece direction
LOC-03 (CCTMS Connection code type)
ZYL cylindrical shank
LOC-03 (CCUMS Connection code unit base)
2 Inch
LOC-03 (CZCMS Connection size code)
0375
LOC-03 (DCONMS Diameter)
9.525 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL03750125
LS (Shank length)
50 mm
LU (Usable length)
30.61 mm
NOF (Flute count)
4
OAL (Overall length)
101.6 mm
PLGL (Plug length)
0.5 mm
RPMX (Rotational speed maximum)
50000 1/min
SRR (Stock removal recommended)
0.3 mm
STDSZ (Size to the standard number)
Working process
REI - Cylindrical reaming
WT (Weight of item)
0.093 kg
