Главная Инструменты 302-05 - Stepped countersinking tool / tapered countersinking tool 452.C1-0950-100T-C CD10

452.C1-0950-100T-C CD10

452.C1-0950-100T-C CD10 452.C1-0950-100T-C CD10 452.C1-0950-100T-C CD10 452.C1-0950-100T-C CD10

452.C1-0950-100T-C CD10

SV - Sandvik-Coromant
Артикул: 6010905
В наличии
0 ₽
В корзину
Описание
Характеристики
BMC (Body material code)
H - Solid carbide
CCONMS (Connection count machine side)
2
CNSC (Coolant entry style code)
0 - Without coolant entry
CXSC (Coolant exit style code)
0 - Without coolant exit
CXSC (Coolant exit style code) / Тип подвода СОЖ
0 - Without coolant exit
DC (Cutting diameter minimum)
9.502 mm
DCP (Data chip provision)
0 - Without data chip
DCX (Cutting diameter 1st step maximum)
20 mm
Delivery state
NL - Discontinued
Delivery state valid from
12/1/2023
DIN
SAC03750385
GRDMFG (Grade manufacturers designation)
CD10
GRDPRIO (Standard designation of the grade main application)
DP
HAND (Cutting direction)
R - Right
Interface codes
J6 / J61
ISO
SAC03B0375$$$$
LCF (Length chip flute)
21.22 mm
LF (Functional length)
15.58 mm
LOC-03 ISO
SAC03B0375$$$$
LOC-03 (CCFMS Connection code form)
03
LOC-03 (CCSMS Connection code style)
5 Shaft in machine direction or hole in workpiece direction
LOC-03 (CCTMS Connection code type)
SAC Screw mounting SANDVIK Coromant
LOC-03 (CCUMS Connection code unit base)
8 non-dimensional size
LOC-03 (CZCMS Connection size code)
0375
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SAC03750385
LS (Shank length)
11.18 mm
NOF (Flute count)
1
OAL (Overall length)
49.5 mm
PHD (Premachined hole diameter)
9.502 mm
RPMX (Rotational speed maximum)
6000 1/min
SIG (Point angle 1st step)
100 Degree
Working process
SPL - Spot facing
WT (Weight of item)
0.08 kg
