Главная Инструменты 403-02 - Driven tool unit - straight offset design C4-DNI-MZ40X-I-B

C4-DNI-MZ40X-I-B

C4-DNI-MZ40X-I-B

C4-DNI-MZ40X-I-B

SV - Sandvik-Coromant
Артикул: 8581776
В наличии
0 ₽
В корзину
Описание
Характеристики
CCFOP (Connection code form output side)
01
CCSWS (Connection code style workpiece side)
5 - Shaft in machine direction or hole in workpiece direction
CCTOP (Connection code type output side)
CCS
CCUWS (Connection code unit base workpiece side)
9 - non-dimensional size with coolant
CNSC (Coolant entry style code)
7 - Coolant entry, decentral and axially concentric
CONARWS (Connection arrangement workpiece side)
CXSC (Coolant exit style code)
1 - With Coolant exit, axial concentric
CXSC (Coolant exit style code) / Тип подвода СОЖ
1 - With Coolant exit, axial concentric
CZCOP (Connection size code output side)
0400
DCP (Data chip provision)
0 - Without data chip
Delivery state valid from
6/1/2024
DIN
FLCD4XD0295
DIN CSW1
CCS04000195
Interface codes
J6 / J61
Interface codes CSW1
J41 / J431
ISO
FLC02CD4XD$$$$
ISO CSW1
CCS01C0400****
LF (Functional length)
130 mm
LOC-01 ISO
CCS01C0400****
LOC-01-Connection-codes
J41 / J441 - Trennstellenkodierung, Abtrieb 1
LOC-01-DIN
CCS04000195
LOC-02 ISO
CCS02C0400****
LOC-02-Connection-codes
J41 / J441 - Trennstellenkodierung, Abtrieb 1
LOC-02-DIN
CCS04000295
LOC-03 ISO
FLC02CD4XD$$$$
LOC-03 (CCFMS Connection code form)
02
LOC-03 (CCSMS Connection code style)
5 Shaft in machine direction or hole in workpiece direction
LOC-03 (CCTMS Connection code type)
FLC Flange mounting SANDVIK Coromant
LOC-03 (CCUMS Connection code unit base)
9 non-dimensional size with coolant
LOC-03 (CZCMS Connection size code)
D4XD
LOC-03 (DCONMS Diameter)
40 mm
LOC-03-Connection-codes
J6 / J61 - Trennstellenkodierung, maschinenseitig
LOC-03-DIN
FLCD4XD0295
LPR (Protruding length)
170 mm
OAH (Overall height)
88 mm
OAL (Overall length)
247 mm
OAW (Overall width)
155 mm
RPMX (Rotational speed maximum)
6000 1/min
WF (Functional width)
70 mm
Working process
No working processes available
WT (Weight of item)
0.001 kg
